SRV3KL IN APC Online UPS

Name: SRV3KL IN APC Online UPS
Brand: NAMRATA POWER SYSTEMS
Price: 41000 INR
Availability: InStock

Price 41000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

SRV3KL IN APC Online UPS Specification

Material
Metal/ABS Body

Efficiency (%)
94%

Port Type
Input: IEC C20, Output: IEC C13/C19

Control System
Microprocessor Controlled

Batteries Type
Sealed Lead Acid

Battery Backup
Up to 30 Minutes (at full load)

Power Capacity
3000 VA / 2400 W

Cooling System
Intelligent Forced Air Cooling

Type
Standby

Phase
Three Phase

Protection
Over Voltage

Output Voltage
230V AC

Recharge Time
3 Hours to 90% Capacity

Back-Up Time
30 Minutes (typical) Depending on Load

Interface Type
USB, RS232, SNMP

Size
438 x 134 x 355 mm

Weight
24 kg

Color
Black

Frequency Range
50/60 Hz Auto Sensing

Mounting Type
Tower

Input Voltage Range
160 - 280V AC

Crest Factor
3:1

Alarm Indicators
Audible and Visual alarms for Battery, Overload & Faults

Display
LCD Panel for Status & Diagnostics

Bypass Mode
Automatic and Manual

Compliance
RoHS, CE, BIS Certified

Humidity Tolerance
0-95% non-condensing

Operating Temperature
0°C to 40°C

Noise Level
< 50 dB at 1 meter

Typical Applications
IT Equipment, Networking Devices, Servers, Data Centers

SRV3KL IN APC Online UPS Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About SRV3KL IN APC Online UPS

Input

Output power capacity	2.4kWatts / 3.0kVA
Max Configurable Power (Watts)	2.4kWatts / 3.0kVA
Nominal Output Voltage	230V
Efficiency at Full Load	90.0 %
Output Frequency (sync to mains)	50/60Hz +/- 3 Hz
Other Output Voltages	220-240
Topology	Double Conversion Online
Waveform type	Sine wave
Bypass	Built-in Maintenance Bypass

Output

Nominal Input Voltage	230V
Input frequency	40 - 70 Hz
Input Connections	IEC-320 C20
Cord Length	1.48meters
Number of Power Cords	1
Efficiency at Full Load	90.0 %

Batteries & Runtime

Battery type	VRLA
Included Battery Modules	1
Typical recharge time	4hour(s)

Communications & Management

Control panel	Multi-function LCD status and control console
Audible Alarm	Audible and visible alarms prioritized by severity
Emergency Power Off (EPO)

Physical

Maximum Height	88MM, 8.8CM
Maximum Width	438MM, 43.8CM
Maximum Depth	632MM, 63.2CM
Rack Height	2U
Net Weight	98.0KG
Shipping weight	32.0KG
Shipping Height	228MM, 22.8CM
Shipping Width	570MM, 57.0CM
Shipping Depth	794MM, 79.4CM
Color	Black

Environmental

Operating Temperature	0 - 40 Degree C
Operating Relative Humidity	0 - 95 (non-condensing) %
Operating Elevation	0-3000meters
Storage Temperature	-20 - 60 Degree C
Storage Relative Humidity	0 - 95 (non-condensing) %
Storage Elevation	0-3000meters
Protection Class IP	20

Advanced Power Protection

The SRV3KL IN APC Online UPS delivers secure and stable power, ensuring essential devices remain protected against surges, overload, and faults. Automatic and manual bypass modes offer added flexibility during maintenance, while audible and visual alarms provide instant notifications for critical events.

Efficient Performance and High Durability

Operating at up to 94% efficiency, the UPS minimizes energy loss and heat generation. Its high-crest factor of 3:1 suits even sensitive electronics, and sealed lead acid batteries enhance reliability. Fast recharge within three hours and a typical 30-minute backup cater to demanding work environments.

User-Centric Control & Monitoring

The integrated LCD panel enables convenient monitoring of the UPS status, with clear diagnostics for troubleshooting. Multiple interfaces like USB, RS232, and SNMP support seamless network integration, allowing users to manage and monitor the system from various locations. Lightweight design and tower mounting make installation straightforward.

FAQ's of SRV3KL IN APC Online UPS:

Q: How does the SRV3KL IN APC Online UPS provide protection during power outages?

A: The SRV3KL IN ensures uninterrupted power by instantly switching to battery backup when the main supply fails. Its microprocessor control, overload, and over-voltage protection mechanisms prevent electrical mishaps and safeguard connected equipment.

Q: What are the typical applications for this UPS model?

A: This UPS is ideal for IT equipment, networking devices, servers, and data centers that require stable, high-quality power. It efficiently supports three-phase setups and caters to both commercial and industrial environments.

Q: When should I use the automatic or manual bypass mode?

A: Engage the automatic bypass during maintenance or faults for continuous power delivery without interrupting equipment operation. Manual bypass allows for safe servicing or testing without disconnecting critical loads.

Q: Where can the SRV3KL IN UPS be installed?

A: Designed as a tower-type UPS, it fits conveniently in server rooms, network closets, or data centers. Its robust construction and compact size make it suitable for most professional electrical setups across India.

Q: What is the process for monitoring and managing this UPS?

A: Users can monitor real-time diagnostics and operational status via the LCD panel. For advanced management, connect through USB, RS232, or SNMP interfaces to integrate with network management systems or software dashboards.

Q: How long does it take to recharge the batteries, and what is the typical backup time?

A: The UPS restores batteries to 90% capacity within three hours. At full load, it typically provides up to 30 minutes of backup, depending on actual power consumption.

Q: What are the main benefits of choosing the SRV3KL IN APC Online UPS?

A: This UPS model offers high efficiency, multiple interface options, comprehensive alarms, and robust environmental tolerance. Users benefit from enhanced protection, improved equipment lifespan, and ensured business continuity during power interruptions.
