SURT20KUXIG-IN APC Smart-UPS On-Line

Main Input Voltage

230 V 1 phase 415 V 3 phases

Other Input Voltage

220-240 V

Main Output Voltage

230 V 1 phase -415 V 3 phases

Other Output Voltage

230 V

Rated power in W

20000 W

Rated power in VA

20000 VA

Output connector type

Hard wire 5 wire (3P + N + E) 1

Hard wire 3-wire (1P + N + E) 1

IEC connector 3-wire (1P + N + E) 1

Number of rack unit

3U

Battery type

External battery system

Provided equipment

1 x installation guide

1 x safety guide

1 x Smart UPS signalling RS-232 cable

Number of battery filled slots

0

Number of battery free slots

0

Number of battery replacement quantity

0

Additional information

Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage

Battery voltage

+/- 192 V

Battery charger power

6074 W rated

Extended runtime

1

Number of battery filled slots

0

Number of power module free slots

0

Number of power module filled slots

0

Redundant

No

Colour

Black

Height

13.1 cm

Width

44.0 cm

Depth

70.0 cm

Product weight

26.5 kg

Mounting location

Front

Mounting preference

Lower

Mounting mode

Rack-mounted

Two post mountable

0

USB compatible

No

Network frequency

40-70 Hz auto sensing

Number of input connectors

1 hard wire 5 wire (3P + N + E)

1 hard wire 3-wire (1P + N + E)

Input voltage limits

160-285 V

380 V 380-415 V

Maximum input current

87 A

Switching current capacity

125 A

Input harmonic distortion

Less than 5 % for full load

Input current

87 A

Load power factor

From 0.9 leading to 1 lagging

Maximum configurable power in W

20000 W

Harmonic distortion

Less than 5 %

Output frequency

50/60 Hz +/- 0.1 Hz sync to mains

Crest factor

3 : 1

UPS type

Double conversion online

Wave type

Sine wave

Output overload operation

60 seconds at 125% and 30 seconds at 150%

Bypass type

Built-in static bypass

Efficiency

93 % (in battery operation)

Maximum configurable power in VA

20000 VA

Ambient air temperature for operation

0-40 Degreev C

Relative humidity

0-95 % non-condensing

Operating altitude

0-3000 m

Ambient air temperature for storage

-15-60  degreev C

Storage Relative Humidity

0-95 % non-condensing

Storage altitude

0-15000 m

Acoustic level

58 dBA

Heat dissipation

3821 Btu/h

IP degree of protection

IP20
